Features
◎ by powder granulation, improve liquidity, reduce dust;
◎ by powder granulation, to improve its solubility;
◎ mixing - granulating - drying - completed (step granulation) in a machine;
◎ made of antistatic filter material, equipment operation safety;
◎ Multi-fluid atomizer adhesive gun, even fog particles, greatly improve the rate of qualified products;
◎ equipment no dead ends, lighter, faster loading and unloading, rinse.
Applications
◎ pharmaceutical granulation and coating
Granulation: tableting granules, powder granules, capsules with granules.
Coating: granule, pill protection layer, color preparation, sustained-release, film, enteric coating.
◎ Food granulation and coating
Sugar, coffee, cocoa powder, cream, powdered juice, acids, seasonings, puffed food.
◎ pesticides, paint pigments, dyes granulation
◎ powder, granules, bulk material drying
Technical Specifications
| Specification | 3 | 5 | 15 | 30 | 45 | 60 | 90 | 120 | 150 | 200 | 300 | 500 |
| Capacity | 12 | 22 | 45 | 100 | 155 | 220 | 300 | 420 | 530 | 660 | 1000 | 1500 |
| Capacity | 1.5/4.5 | 4/6 | 10/20 | 15/45 | 25/65 | 40/80 | 60/120 | 80/160 | 90/200 | 100/300 | 150/450 | 300/300 |
| Fan power | 2.2 | 3 | 4 | 5.5 | 7.5 | 11 | 15 | 18.5 | 18.5 | 22 | 30 | 37 |
| Fan steam consumption | 12 | 23 | 42 | 70 | 99 | 141 | 169 | 211 | 251 | 282 | 366 | 451 |
| Compressed air consumption | 0.3 | 1.3 | 0.3 | 0.4 | 0.4 | 0.6 | 0.6 | 0.9 | 0.9 | 0.9 | 1.3 | 1.5 |
| Noise | (Fan installed separately) ≤75 | |||||||||||
| Dimensions |
1.0 ×0.55 ×1.8 |
1.2 ×0.6 ×2.1 |
1.25 ×0.9 ×2.1 |
1.6 ×0.9 ×2.3 |
1.65 ×1.1 ×2.4 |
1.85 ×1.25 ×3 |
1.85 ×1.25 ×3 |
2.2 ×1.65 ×3.1 |
2.27 ×1.72 ×3.1 |
2.34 ×1.9 ×3.5 |
2.8 ×1.9 ×3.8 |
3 ×2.55 ×4.2 |
NOTE: FG without granulation section
