Product description
I produced the spiral finned air heat exchanger, also known as radiators, radiator pipe,
It is a heat exchanger means for cooling or heating medium hot and cold air in the main equipment.br /> Adapt materials
Radiator for hot-air heating, air conditioning, cooling, dehumidification and drying works for steam or hot water can be heated air by salt water or cold water to cool the air. It is widely used in the mining industry, light industry, papermaking, chemical, defense, textiles, electricity, dairy products, ceramics, hospitals, theaters and other air conditioning systems, the structure is composed of finned tubes, spiral finned tubing series, various models have different size specifications.
Superheated steam or thermal oil as the heat source is the fin specifications
| Stainless steel | Carbon steel | Aluminum | |
| Specifications diameter | Φ18×2 | Φ19×2 | - |
| The outer diameter of the fin | Φ38 | Φ39 | - |
| Fin thickness | 0.24 | - | 0.4 |
| Heat transfer area coefficient | 0.64 |
Heat source is hot air finned tube specifications
| Specifications diameter | Φ63×3 |
| The outer diameter of the fin | Φ103 |
| Fin thickness | 1.5 |
| Heat transfer area coefficient | 1.5 |
Ordering Information
It can be equipped with various drying equipment, specifications and diverse species, the use of materials: aluminum, stainless steel, A3 steel zinc plated, steel-aluminum, copper, steel and aluminum winding sheet. In addition, the radiators can be used for indoor heating and dehumidification Treasury Our company is designed for users.
◎When ordering, you must explain product type, name, specified tube length, number of tubes and Rows.
◎When ordering, if there are special requirements and specifications subject to recommendations, supporting a variety of drying equipment, specifications and diverse species, the use of materials: aluminum, stainless steel, A3 steel zinc plated, steel-aluminum, copper, steel and aluminum winding sheet. In addition, the radiators can be used for indoor heating and dehumidification Treasury Our company is designed for users.
