working principle
The stirred materials to the required particle size, or blocked raw materials into small particles.
Adapt materials
This machine is suitable for pharmaceutical, chemical, food and beverage industry, solid granulation.
Technical Specifications
| Model | YK160 | YK320 |
| Production capacity | 50-200 kg/h | 50-400 kg/h |
| Motor Power | 2.2kw | 7.5kw |
| Roller Speed | 65rpm | 65rpm |
| Swing angle | 360o | 360o |
| Roller diameter | Φ160mm | Φ320mm |
| Weight | 450kg | 750kg |
| Dimensions | 1000×800×1300m | 1500×1200×1500m |
